Specifications
1.Compact structured,
2.Precise cutting-off position,
3.Swift and labor-saving for changing
4. CE, ISO certification
Characteristic:
1,Electromechanical integration design, cultivating excellent electrical control system, is easy to operate, reliable operation, high automatic positioning accuracy.
2,Bottle equipment is advanced, abandon the past screw bottle device, bottle spacing control accurate, not easy clamp bottle to bottle, nor grinding bottle, in the industry to outshine others.
3,Convenient man-machine dialogue type operation, intuitive, clear and concise.
4,Advanced and convenient automatic feeding device, effectively avoid scale inertia, maintain the reasonable tension label contract.
5,Applicability is wide and within the scope of the effective diameter, whether packaging is round, square or other different traits of PET bottle, glass bottle, etc all can use.
Technical parameters:
|
input power
|
2kw
|
|
input voltage
|
3,380/220VAC
|
|
production efficiency
|
150bottle/min
|
|
size of host machine
|
L2100mm*W850mm*H2000mm
|
|
applicable diameter of bottle body
|
28-120mm
|
|
applicable length of label
|
30-250mm
|
|
applicable thickness of label
|
0.03-0.13mm
|
|
applicable internal diameter of paper tube
|
5’’-10’’ free to adjust
|
