Specifications
1,For non carbonated drink,as Mineral water
2, Suit for 300ml-2000ml bottle
3,sealing machine line
4,CE, ISO certification
Machine advantage:
1, It is the ideal line for food and drink factory
2, It is Suit for 300ml-2000ml bottle
3, It used for plastic bottle, glass bottle
4, Our company have passed CE, ISO certification
Usage:
1. suspension technology and neck-locking structure to assure the convenience of changing bottles
2. whole equipment controlled by PLC system
3. equal pressure filling in high accuracy
4. capping system in magnetic technology with non-hurting
5. cap sorter in rotary running with check sensors
6. low noise transmission, running, and working
Characteristic:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Beverage Machinery-Main technical parameters:
Main technical parameters:
|
Model
|
GFP-12
|
GFP-24
|
GFP-32
|
|
Production Capacity
|
1500-2000B/H
|
3000-5000B/H
|
6000-8000B/H
|
|
Bottle/ Can Type
|
Glass bottle, PET bottle, Pop-top bottle
|
|
Inner dia. at inlet
|
15-18 15-18 53-65
|
|
Outer dia. of bottle
|
60-80 60-80 90-133
|
|
Bottle height
|
200-320 200-320
|
|
Power
|
0.75KW
|
1.1KW
|
1.5KW
|
|
Overall Dimension
|
1000× 800 × 2000mm
|
1330× 1260×2200mm
|
1450×1700×2500mm
|
|
Weight
|
1200Kg
|
1600Kg
|
2000Kg
|
Why our machine is better than other similar machines
1. Small profits and quick returns is our business policy, so the water bottling line is worth every cent.
2. We focus on advanced supply chain management, which can ensure the raw materials are with
good quality and competitive price.
3. Workers, engineers and boss of our company have spent more than 10 years in beverage
machinery industry,so they have rich experience to provide Turn Key project Service.
4. There are several engineers available to oversea service. As long as our customers need them,
they can leave for your country as soon as possible, our principle to let our production line always runsnormally.
5. We can update the production status for our customer once per week, our target is to let our
customer receive goods on time.
About our company
We can provide beverage filling line as below:
1).Complete mineral & pure water production line
2).Complete fruit juice production line
3).Complete soft drink production line
4).Gallons water production line
5). Beer filling & packaging line
We strictly manufacture and manage according to IOS9001 System.And we sincerely welcome customers all over the world visit our company,or visit our website.
After-sale servic
1. 1 year quality warranty and supply spare parts at low cost for life span after sale. We keep the original drawings of spare parts, so it can match with the rest part of machine.
2. 24 hours/365 days online technical service.
3. Training offered
Welcome to check our complete water bottling line
For any further information about it,please contact us without hesitation,we will reply to you asap.Thank you.
