Specifications
1,For non carbonated drink,as Mineral water
2, Suit for 300ml-2000ml bottle
3,sealing machine line
4,CE, ISO certification
Machine advantage:
1, It is the ideal line for food and drink factory
2, It is Suit for 300ml-2000ml bottle
3, It used for plastic bottle, glass bottle
4, Our company have passed CE, ISO certification
Usage:
1. suspension technology and neck-locking structure to assure the convenience of changing bottles
2. whole equipment controlled by PLC system
3. equal pressure filling in high accuracy
4. capping system in magnetic technology with non-hurting
5. cap sorter in rotary running with check sensors
6. low noise transmission, running, and working
Characteristic:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Main technical parameters:
|
Model
|
GFP-12
|
GFP-24
|
GFP-32
|
|
Production Capacity
|
1500-2000B/H
|
3000-5000B/H
|
6000-8000B/H
|
|
Bottle/ Can Type
|
Glass bottle, PET bottle, Pop-top bottle
|
|
Inner dia. at inlet
|
15-18 15-18 53-65
|
|
Outer dia. of bottle
|
60-80 60-80 90-133
|
|
Bottle height
|
200-320 200-320
|
|
Power
|
0.75KW
|
1.1KW
|
1.5KW
|
|
Overall Dimension
|
1000× 800 × 2000mm
|
1330× 1260×2200mm
|
1450×1700×2500mm
|
|
Weight
|
1200Kg
|
1600Kg
|
2000Kg
|
