Specifications
Outside bottle brushing machine
1)quality machines and best price
2)capcity:450 bph
3)CE compliant
4)delivery time:15 days
Outside bottle brushing machine
The bottle goes into the outside cleaning machine by the action of conveyor and bottle closed to the main rotate brusher .the direction of main brushing rotate is opposite with the bottle and bottle bottom brusher rotate direction . The bottle finish revolution one circle, self rotate running. Washing pump offer the water or cleaning liquid to every brusher. And the liquid can be recycled because of the bottom water tank. The bottle in the outside brushing machine rotates 270°.then goes into the spray room. After spraying, the bottle carried out by conveyor .the spraying room water can from the same washing pump, and the water also can be recycled to use.
Main technical parameters
|
Items
|
Specification
|
|
Production capacity
|
300 Buckets/hour
|
|
Bottle’s specification (mm)
|
Φ270×490×Φ56
|
|
Rated input power
|
4.5KW
|
|
Water tank heating tube power
|
2KW×2
|
|
Electromotor power
|
Conveying electromotor
|
0.50 KW
|
|
Brush pump
|
0.70 KW
|
|
Alkali (medicine) Washing pump
|
0.37 KW
|
|
Tap water washing pump
|
0.37 KW
|
|
Input Voltage
|
AC 380V±5%/220/110 50/60Hz
|
|
Rated current
|
15A
|
|
Net weight
|
300kg
|
|
Outer size
|
3290×900×1650(mm)
|
machine photo
contact us
1. Water treatment system (purified water and mineral water)
2. 3 in 1 monoblock purified & mineral water filling machine
3.3 in 1 monoblock juice & tea filling machine
4.3 in 1 monoblock carbonated drink filling machine
5. Monomer type filling machine – for water, CSD, juice, tea, oil, wine, beer, etc.
6. 3 to 5 gallon barrel water filling machine
7. Pop can filling machine
8. packing system – labeler, printer, shrink wrapping packager etc.
9. PET bottles blowing machine
10.Botte unscrambling machine
11.Other auxiliary equipment
What you need is a complete beverage production line from A to Z, that is okay and we can supply it to you.
